Content elements¶

Schema¶

Placeholders¶

The schema content element is used to insert structured data in JSON-LD format into the body tag by means of a script tag. It allows to use placeholders in the JSON-LD code for TS constants, getText data types and the processedData array. The following table shows some placeholder examples:

Placeholder example	Type	Description
`{$pizpalue.customer.contactName}`	TS Constant	Used as for TS setup: `{$constantName}`
`{data:field.teaser}`	getText	Wrap getText definition with `{data:\|}`. When using the key `field` data from the current content record (`tt_content`) is obtained.
`{processedData:schemaImages.0}`	processedData array	Wrap the processedData array path with `{processedData:\|}` In case the value from the `processedData` array is an instance of `FileReference` the url to the file is obtained.

Functions¶

Additionally the obtained data can be passed to a function. The following functions are available:

Function	Example usage	Description
`entityEncodeChars`	`{func:entityEncodeChars:info@domain.ch}`	Each character from `info@domain.ch` will be converted to its entity. For example `i` will be converted to `i`
`entityEncodeChars`	`{func:entityEncodeChars:{$cust.email}}`

Content¶

In the content element an image and a text can be defined. They might be used in the JSON-LD data with the following placeholders:

Content	Placeholder
Text	`{data:field.teaser}`
Image	`{processedData:schemaImages.0}`

Example¶

For this example an image as well as a text have been added to the content element. The image will be used for the logo and the text for the description property.

JSON-LD-code in content element:

{
  "@context" : "http://schema.org",
  "@type" : "Organization",
  "name": "{$pizpalue.customer.company}",
  "email": "{func:entityEncodeChars:{$pizpalue.customer.contactEmail}}",
  "telephone": "{$pizpalue.customer.contactPhone}",
  "faxNumber": "{$pizpalue.customer.contactFax}",
  "url" : "https://www.{$pizpalue.customer.domain}",
  "logo": "{processedData:schemaImages.0}",
  "description": "{data:field:teaser}",
  "address": {
    "@type": "PostalAddress",
    "addressLocality": "{$pizpalue.customer.contactCity}, Switzerland",
    "postalCode": "CH-{$pizpalue.customer.contactZip}",
    "streetAddress": "{$pizpalue.customer.contactAddress}"
  },
  "contactPoint" : [
    { "@type" : "ContactPoint",
      "telephone" : "{$pizpalue.customer.contactPhone}",
      "contactType" : "customer service"
    }
  ]
}

JSON-LD-code embedded into body tag:

{
  "@context" : "http://schema.org",
  "@type" : "Organization",
  "name": "Company GmbH",
  "email": "&#99;&#111;&#110;&#116;&#97;&#99;&#116;&#64;&#100;&#111;&#109;&#97;&#105;&#110;&#46;&#99;&#104;",
  "telephone": "111 111 11 11",
  "faxNumber": "111 111 11 12",
  "url" : "https://www.domain.ch",
  "logo": "http://pp10.buechler.pro/fileadmin/_processed_/3/9/csm_geran-de-klerk-136351_2571a74988.jpg",
  "description": "Development of mobile phones powered by propietary OS to guarantuee privacy.",
  "address": {
    "@type": "PostalAddress",
    "addressLocality": "Ort, Switzerland",
    "postalCode": "CH-1111",
    "streetAddress": "Strasse 1"
  },
  "contactPoint" : [
    { "@type" : "ContactPoint",
      "telephone" : "111 111 11 11",
      "contactType" : "customer service"
    }
  ]
}
