Widgets

You can add the Matomo widgets like any other widget to a dashboard. Please note, that the widgets have to be enabled in the site configuration and the permissions for editors have to be granted to be able to use these widgets.

Hint

Most widgets need an activated module in Matomo to work. If a module is not available, an error is displayed in the widget. The parameters of the underlying data providers can be adjusted. Have a look into the Widget configuration section.

The following widgets are available. A link to the corresponding page in Matomo is displayed via in icon in the header bar of the widget if the report is available.

Tip

Do you miss a widget? Open a feature request and with a little luck the widget is available in the next release.

Actions per day

This widget displays the number of actions per day for the last 28 days (including the current day). Actions are:

Page views
Downloads
Clicks on outlinks

Widget Actions per day — Widget *Actions per day*

Matomo module

VisitsSummary

Active widgets value in config.yaml

actionsPerDay

Default configuration parameters in the Configuration/Services.yaml file

matomo_widgets.actionsPerDay.parameters

period: day
date: last28

Actions per month

This widget displays the number of actions per month for the last 12 months (including the current month). Actions are:

Page views
Downloads
Clicks on outlinks

Widget Actions per month — Widget *Actions per month*

Matomo module

VisitsSummary

Active widgets value in config.yaml

actionsPerMonth

Default configuration parameters in the Configuration/Services.yaml file

matomo_widgets.actionsPerMonth.parameters

period: month
date: last12

Annotations

Display a list of the recent annotations in the last 365 days:

Matomo module

Annotations

Active widgets value in config.yaml

annotations

Default configuration parameters in the Configuration/Services.yaml file

matomo_widgets.annotations.parameters

period: 'month'
date: 'today'
lastN: 365

Create annotation

This widget provides a form to create an annotation conveniently from the TYPO3 backend:

After submitting the form, a notification is displayed in the upper right corner of the browser window. If the creation of the annotation was successful, the Note field will be cleared.

Matomo module: Annotations
Active widgets value in config.yaml: createAnnotation

Note

The annotation is stored in Matomo under the user configured in the site configuration. A log entry has been created that can be viewed in the System > Log module. In addition to the user, the date, the note and the note ID received are saved:

Note

For the creation of an annotation the according Matomo user needs only the view permission.

Bounce rate

Changed in version 3.0

The bounce rate for the last 28 days is displayed. In older versions the rate for the current month has been shown.

The bounce rate for the last 28 days shows this widget:

Widget Bounce Rate — Widget *Bounce rate*

Matomo module

VisitsSummary

Active widgets value in config.yaml

bounceRate

Default configuration parameters in the Configuration/Services.yaml file

matomo_widgets.bounceRate.parameters

period: range
date: last28

matomo_widgets.bounceRate.subtitle

in the last 28 days (incl. today)

Browser plugins

Changed in version 3.0

The numbers for the last 28 days are displayed. In older versions the numbers for the current month have been shown.

This report shows which browser plugins your visitors had enabled in the last 28 days:

Widget Browser Plugins — Widget *Browser Plugins*

Matomo module

DevicePlugins

Active widgets value in config.yaml

browserPlugins

Default configuration parameters in the Configuration/Services.yaml file

matomo_widgets.browserPlugins.parameters

period: range
date: last28
filter_limit: 50
filter_sort_column: nb_visits
filter_sort_order: desc

Browsers

Changed in version 3.0

The numbers for the last 28 days are displayed. In older versions the numbers for the current month have been shown.

The browser share for the last 28 days shows this widget:

Matomo module

DevicesDetection

Active widgets value in config.yaml

browsers

Default configuration parameters in the Configuration/Services.yaml file

matomo_widgets.browsers.limit

5

matomo_widgets.browsers.parameters

period: range
date: last28
filter_sort_column: nb_visits
filter_sort_order: desc

Campaigns

Changed in version 3.0

The numbers for the last 28 days are displayed. In older versions the numbers for the current month have been shown.

Displays a report of the campaigns for the last 28 days:

Matomo module

Referrers

Active widgets value in config.yaml

campaigns

Default configuration parameters in the Configuration/Services.yaml file

matomo_widgets.campaigns.parameters:

period: range
date: last28
filter_limit: 30
filter_sort_column: nb_visits
filter_sort_order: desc

Content names

Changed in version 3.0

The numbers for the last 28 days are displayed. In older versions the numbers for the current month have been shown.

The content name report is part of content tracking. The widget displays the names, impressions and interaction rate of the content the visitors viewed and interacted with.

Widget Content Names — Widget *Content Names*

Matomo module

Contents

Active widgets value in config.yaml

contentNames

Default configuration parameters in the Configuration/Services.yaml file

matomo_widgets.campaigns.parameters:

period: range
date: last28
filter_limit: 50
filter_sort_column: nb_impressions
filter_sort_order: desc

Content pieces

Changed in version 3.0

The numbers for the last 28 days are displayed. In older versions the numbers for the current month have been shown.

The content piece report is part of content tracking. The widget displays the pieces, impressions and interaction rate of the content the visitors viewed and interacted with.

Widget Content Pieces — Widget *Content Pieces*

Matomo module

Contents

Active widgets value in config.yaml

contentPieces

Default configuration parameters in the Configuration/Services.yaml file

matomo_widgets.campaigns.parameters:

period: range
date: last28
filter_limit: 50
filter_sort_column: nb_impressions
filter_sort_order: desc

Countries

Changed in version 3.0

The numbers for the last 28 days are displayed. In older versions the numbers for the current month have been shown.

Shows a list of countries from which the website was visited in the last 28 days:

Matomo module

UserCountry

Active widgets value in config.yaml

countries

Default configuration parameters in the Configuration/Services.yaml file

matomo_widgets.country.parameters:

period: range
date: last28
filter_limit: 50
filter_sort_column: nb_visits
filter_sort_order: desc

Custom dimensions

Changed in version 3.0

The numbers for the last 28 days are displayed. In older versions the numbers for the current month have been shown.

With custom dimensions any custom data can be assigned to visitors or actions. Before a custom dimension can be used as a dashboard widget it has to be configured for a site.

The columns for a custom dimension widget depend on the scope of the custom dimension.

Matomo module

CustomDimensions

Default configuration parameters in the Configuration/Services.yaml file

matomo_widgets.customDimension<idDimension>.parameters:

period: range
date: last28
filter_limit: 50
filter_sort_column: nb_visits
filter_sort_order: desc

The <idDimension> is the ID of the custom dimension as available in the Matomo configuration.

Scope "action"

Scope "visit"

JavaScript errors

Displays a list of JavaScript errors that occurred in the last 14 days:

Clicking on the message opens a modal with details to this message:

Matomo module

Events

Active widgets value in config.yaml

javaScriptErrors

Default configuration parameters in the Configuration/Services.yaml file

matomo_widgets.javaScriptErrors.parameters:

period: range
date: last14
filter_limit: 50
filter_sort_column: nb_events
filter_sort_order: desc

Note

To use this widget, JavaScript error tracking must be activated. This can be done either by adding the enableJSErrorTracking code or by enabling the corresponding option in the installed Matomo Integration extension.

Link to Matomo

A call-to-action widget is used to show a link to the configured Matomo installation:

Active widgets value in config.yaml: linkMatomo

Most viewed pages

Changed in version 3.0

The numbers for the last 28 days are displayed. In older versions the numbers for the current month have been shown.

Show the most viewed pages of a site for the last 28 days:

Widget Most viewed pages — Widget *Most viewed pages*

Matomo module

Actions

Active widgets value in config.yaml

mostViewedPages

Default configuration parameters in the Configuration/Services.yaml file

matomo_widgets.mostViewedPages.parameters:

period: range
date: last28
filter_sort_column: nb_hits
filter_sort_order: desc

Tip

When you see URLs with the addition "- Others" then Matomo groups pages automatically after a given limit: You can increase the limit. Maybe you want then invalidate the historical reports to adopt the change.

Operating system families

Changed in version 3.0

The numbers for the last 28 days are displayed. In older versions the numbers for the current month have been shown.

The operating system families used by the visitors for the last 28 days:

Widget Operating system families — Widget *Operating system families*

Matomo module

DevicesDetection

Active widgets value in config.yaml

osFamilies

Default configuration parameters in the Configuration/Services.yaml file

matomo_widgets.osFamilies.limit:

5

matomo_widgets.osFamilies.parameters:

period: range
date: last28
filter_sort_column: nb_visits
filter_sort_order: desc

Pages not found

List of pages in the last 28 days which returned a status code 404 (not found):

Matomo module

Actions

Active widgets value in config.yaml

pagesNotFound

Default configuration parameters in the Configuration/Services.yaml file

matomo_widgets.siteSearchKeywords.parameters:

period: range
date: last28
filter_limit: 50
filter_sort_column: nb_hits
filter_sort_order: desc

Site search keywords

Changed in version 3.0

The numbers for the last 28 days are displayed. In older versions the numbers for the current month have been shown.

Overview of the search keywords that visitors searched for on the internal search engine:

Widget Site search keywords — Widget *Site search keywords*

Matomo module

Actions

Active widgets value in config.yaml

siteSearchKeywords

Default configuration parameters in the Configuration/Services.yaml file

matomo_widgets.siteSearchKeywords.parameters:

period: range
date: last28
filter_limit: 50
filter_sort_column: nb_visits
filter_sort_order: desc

Site search keywords with no result

Changed in version 3.0

The numbers for the last 28 days are displayed. In older versions the numbers for the current month have been shown.

List of the site search keywords that did not return any search result:

Widget Site search keywords with no result — Widget *Site search keywords with no result*

Matomo module

Actions

Active widgets value in config.yaml

siteSearchNoResultKeywords

Default configuration parameters in the Configuration/Services.yaml file

matomo_widgets.siteSearchNoResultKeywords.parameters:

period: range
date: last28
filter_limit: 50
filter_sort_column: nb_visits
filter_sort_order: desc

Visits per day

This widget displays the number of visits per day for the last 28 days:

Matomo module

VisitsSummary

Active widgets value in config.yaml

visitsPerDay

Default configuration parameters in the Configuration/Services.yaml file

matomo_widgets.visitsPerDay.parameters:

period: day
date: last28

Visits per month

This widget displays the number of visits per month for the last 12 months:

Matomo module

VisitsSummary

Active widgets value in config.yaml

visitsPerMonth

Default configuration parameters in the Configuration/Services.yaml file

matomo_widgets.visitsPerMonth.parameters:

period: month
date: last12
