Adding Elements to the Content Element Wizard

The content elements wizard is opened when a new content element is created.

The content element wizard can be fully configured using TSConfig.

Our extension key is example and the name of the content element or plugin is registration.

  1. Create Page TSconfig

    Configuration/TsConfig/Page/Mod/Wizards/NewContentElement.tsconfig:

    mod.wizards {
        newContentElement.wizardItems {
            plugins {
                elements {
                    example_registration {
                        iconIdentifier = example-registration
                        title = Registration Example
                        description = Create a registration form
                        tt_content_defValues {
                            CType = list
                            list_type = example_registration
                        }
                    }
                }
            }
        }
    }


    You may want to replace title and description, using language files for translation, for example:

    title = LLL:EXT:example/Resources/Private/Language/locallang.xml:registration_title
    description = LLL:EXT:exapmle/Resources/Private/Language/locallang.xml:registration_description

  2. Include TSconfig

    ext_localconf.php:

    \TYPO3\CMS\Core\Utility\ExtensionManagementUtility::addPageTSConfig(
        '<INCLUDE_TYPOSCRIPT: source="FILE:EXT:example/Configuration/TsConfig/Page/Mod/Wizards/NewContentElement.tsconfig">'
    );


    This always includes the above Page TSconfig. It is better practice to make this configurable by registering the file as static Page TSconfig:

  3. Register your icon with the icon API

    In ext_localconf.php:

    $iconRegistry = \TYPO3\CMS\Core\Utility\GeneralUtility::makeInstance(\TYPO3\CMS\Core\Imaging\IconRegistry::class);

    // use same identifier as used in TSconfig for icon
    $iconRegistry->registerIcon(
       // use same identifier as used in TSconfig for icon
       'example-registration',
       \TYPO3\CMS\Core\Imaging\IconProvider\FontawesomeIconProvider::class,
       // font-awesome identifier ('external-link-square')
       ['name' => 'external-link-square']
    );

  4. After clearing cache, create a new content element

    You should now see the icon, title and description you just added!

    ../../_images/ContentElementWizard.png

    Content Element Wizard with the new “Event Registration” plugin

See also

Add Your Plugin or CE to Different Tab

The above example adds your plugin to the tab “Plugin” in the content element wizard. You can add it to one of the other existing tabs or create a new one.

Tip

Look in the Info module > Page TSconfig for existing configuration of mod.wizards.newContentElement.wizardItems.

If you add it to any of the other tabs (other than plugins), you must add the name to show as well:

mod.wizards.newContentElement.wizardItems.common {
    elements {
        example_registration {
            iconIdentifier = example-registration
            title = Example title
            description = Example description
            tt_content_defValues {
                CType = list
                list_type = example_registration
            }

    }
    show := addToList(example_registration)
}
  • When you look at existing Page TSconfig in the Info module, you may notice that show has been set to include all for the “plugins” tab:
show = *

Create a New Tab

See bootstrap_package for example of creating a new tab “interactive” and adding elements to it:

mod.wizards.newContentElement.wizardItems {
    interactive.header = LLL:EXT:bootstrap_package/Resources/Private/Language/Backend.xlf:content_group.interactive
    interactive.elements {
        accordion {
            iconIdentifier = content-bootstrappackage-accordion
            title = LLL:EXT:bootstrap_package/Resources/Private/Language/Backend.xlf:content_element.accordion
            description = LLL:EXT:bootstrap_package/Resources/Private/Language/Backend.xlf:content_element.accordion.description
            tt_content_defValues {
                CType = accordion
            }
        }
    }
}
